Whale Supersub 1100 12V with NRV Bilge Pump

Click on an image to display a larger detailed image.

Whale Supersub 1100 12V with NRV Bilge Pump


RRP £46.52


Size: SS1012



High capacity, narrow, low profile submersible bilge pump. Designed to be used with a separate bilge switch. Low profile electric bilge pump perfect for narrow bilge spaces. Supersubs fit where other pumps won't in small or awkward bilge spaces.

  • Drains to down 9mm (1/3")
  • Simple Plumbing
  • Rotate ports to suit your installation.
  • Reliable Long Term
  • Includes extra long wires for integirty
  • Versatile Installation
  • Multi-position pump body and head
  • Easy Maintenance
  • Unique strainer easily cleaned
  • Efficient Operation
  • Low profile strainer
  • Integrated Bleed Ball
  • Prevents airlocks

  • Low narrow design for confined bilge spaces
  • Simple to install - rotate outlet and pump body to suit installation.
  • High performance
  • Efficient operation - power consumption very low
  • Easily cleaned - snap fit assembley
  • Low profile strainer - leaves bilge almost dry

  • It is important to ensure that the system incorporates a vented anti-syphon loop

Awards & Accreditations
  • PBO's Tester Choice
  • CE certified

Approvals & Standards
  • Conforms to ISO 8849 and ISO 15083
  • Ignition protected under ABYC and USCG standards
  • EMC compliant. NMMA type accepted.

  • Open Flow Rate: 1050 US GPH (66 Litres/min) at 27.2V D.C.
  • Flow Rate at 1m (3ft) Head: 750 US GPH (47 Litres/min)
  • Nominal Voltage: 12V D.C.
  • Current Draw: 4.3 Amp
  • Recommended Fuse Size (Automotive): 5 Amp
  • Weight: 400g (0.9lbs)
  • Hose Connections: 25mm/28mm (1"/ 1 1/8") Stepped Ports
  • Minimum Wire Size: 1.5mm² (16 AWG)

  • Pump Body: Polypropylene, High Temperature ABS
  • Locking Ring: Acetal
  • Impeller: Glass-Filled PBT
  • Seals: Nitrile
  • Fasteners: Stainless Steel

Materials in Contact with Fluid
  • Polypropylene
  • ABS
  • Glass-Filled PBT
  • Nitrile
Size / ColourPart NumberStock AvailabilityPrice
SS101299383077 1 at 04/07 12:44 £39.95 Add to Basket
